Cordona Quick shifter Blipper Ducati Panigale V4

Brands of products

Original price was: 2.053,00 د.إ.Current price is: 1.944,00 د.إ.

Brand: Cordona

Cordona quickshifter blipper for Ducati Panigale V4 959.

Estimated Delivery: Wed, 19 Feb 2025 - Mon, 24 Feb 2025
  ... people are viewing this right now

  Share
-GP ASG Superbike Quickshifter – Blipper
-Application: Ducati Panigale V4 fits all years.
-Interface: ‘plug and play’The Cordona analogue 0-5v load cell with strain gauge technology from MotoGP, gives your gear shifts a significant upgrade in performance.
-You will experience a faster, smoother and more distinct gear shift performance that affect your bike chassis less than any OEM shifter.
-The completely sealed sensor without moving parts gives a far better reliability than any OEM shifter.
-The new introduced EVO version have a digitally ‘spring-loaded’ output signal which results in even faster shifts for many bikes from street, adventure to superbikes.
Included:
  • Complete gear linkage
  • 125mm* aluminium rod with M6 left and right threads,
  • left and right rod ends/uniballs**
  • left-right nut-stud
  • 4 cable ties
  • 3M Velcro

@ 0-5v analogue high sensitive Strain Gauge GP ASG Superbike load cell
@ strain gauge technology, no moving parts in sensor
@ linear analogue output to bike ECU, 2.5v (at neutral gear), range 300N to 0.5v/4.5v
@ the EVO version have a output signal with ‘rate dependent hysteresis’ character
@ configurable push or pull direction
@ 5-15v DC power supply
@ 20MHz processor with adaptive calibration for temperature & vibration
@ max temperature sensor 125°C (150°C for short periods), electronic module 85°C
@ temperature drift <0.04% within operation range -10°C to 125°C.
@ completely sealed and weather protected (IP68) sensor and module
@ high precision CNC machined stainless steel housing
@ dimensions; 45mm long, 14mm diameter
@ total weight sensor-electronics 55g, complete linkage incl. rod-uniballs 120g
@ M6 ’magical’ threads, left and right threads in both sensor ends
@ CE mark (EMC radiated)



*different rod lengths can be ordered if needed, see Spare part and Installation Materials.
** high spec SKF racing rod ends/uniballs can be ordered separately, see Spare part and Installation Materials.Technical specification
